ASUS ASUS ROG STRIX B860-I GAMING WIFI B860 LGA 1851 mITX Mini-ITX motherboard, Intel® Core™ Ultra Series (ROG STRIX B860-I GAMING WIFI)

Stok : Limited

Brand: ASUS | SKU: ROG STRIX B860-I GAMING WIFI

Spesifikasi:

Model: ROG STRIX B860-I GAMING WIFI

CPU:
Support Intel® Core™ Ultra Processors
(Series 2)*
Supports Intel® Turbo Boost Technology 2.0
and Intel® Turbo Boost Max Technology 3.0**

Chipset: Intel® B860 Chipset

Memory:
2 x DIMM slots, max. 128GB, DDR5
Supports up to 9066+MT/s (OC), Non-ECC
Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*
Dual channel memory architecture
DIMM Fit
Supports Intel® Extreme Memory Profile
(XMP) memory module
ASUS Enhanced Memory Profile III (AEMP III)

Graphics:
1 x DisplayPort**
1 x HDMI™ port***
1 x Intel® Thunderbolt™ 4 supports
DisplayPort and Thunderbolt™ video outputs****

Storage:
Total supports 2 x M.2 slots and 4 x SATA
6Gb/s ports*
Intel® Core™ Ultra Processors (Series 2)
M.2_1 slot (Key M), type 2260/2280
(supports PCIe 5.0 x4 mode)
Intel® B860 Chipset**
M.2_2 slot (Key M), type 2242/2260/2280
(supports PCIe 4.0 x4 mode)
4 x SATA 6Gb/s ports

Ethernet:
1 x Intel® 2.5Gb Ethernet
ASUS LANGuard

BIOS: 256Mb Flash ROM, UEFI AMI BIOS

Manageability: WOL by PME, UEFI PXE

Operating System: Windows 11 (22H2 & later)

Form Factor:
Mini-ITX Form Factor
6.7 inch x 6.7 inch ( 17 cm x 17 cm )
